F4808 server chassis supports 12"*13" motherboard, three 12038 ball fans with good cooling effect, supports ATX power supply and CRPS power supply, supports 8 standard PCIE expansion slots,
AI, edge computing, deep learning, rendering, GPU computing and other fields
F4808 server chassis supports 12"*13" motherboard, three 12038 ball fans with good cooling effect, supports ATX power supply and CRPS power supply, supports 8 standard PCIE expansion slots, supports up to 3 double-width GPUs, supports 4 A built-in 2.5" SSD, widely used in rendering, GPU computing and other fields.
| Components | Specification |
| Size(mm) | Depth 480mm × width 437.5mm × height 176.5mm, standard 19" rackmount server chassis |
| Material | Environmental protection, anti-fingerprint 1.0mm/SGCC |
| Drivers bay | 4 built-in 2.5" sata/U.2 hard drives |
| Cooling Fan | Three 12038B hot-swappable fans are standard, and two 8038B ball fans are optional for the rear window |
PCIe channel | 8 full-height PCI/PCIE expansion slots, supporting 3 double-width GPUs |
| M/B form factor | Standard 12"*13" and below motherboards |
| USB interface | 2 front USB2.0 ports |
| Indicator lights and switches | 1*Power LED，1*HDD LED，2*NIC LED，1*Power SW，1*Reset |
| Power supply | Support ATX power supply and CRPS redundant power supply |
| Color | The handle and hanging lugs are sandblasted and oxidized to bright black, the front panel components are sprayed with sand grain black, and the rest of the steel plates are of natural color |
| Packing | Pearl cotton + inner box + corner guard + outer box |
| Application field | AI, edge computing, deep learning, rendering, GPU computing and other fields |
