Cloud storage, cloud computing, big data, security monitoring, etc.
| Components | Specification |
| Dimensions(WxDxH) | 437.5mm x 650mm x 177mm. |
| Materials | Quality fine 1.0mm SGCC steel. |
| Color | Black. |
| Drivers bay | Support 8 x 3.5" HDD drive bays, compatible 2.5" HDD/SSD. |
| Cooling Fan | 3 X 12028 hot plug fans. |
| Backplate | 12Gb Mini-sas HD, Optional 6Gb SATA. |
| PSU form factor | Standard ATX power supply Or 2U redundant power supply. |
| M/B form factor | Support MAX 12"×13" motherboard. |
| Epansion space | 8 PCI/PCIE expansion slots. |
| Connector | Two front accessible USB3.0 ports. |
| System Control | Power LED*1, Reset*1, Power SW*1, HDD LED*1, NIC LED*2. |
| Applicarion | Cloud storage, cloud computing, big data, security monitoring, etc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to 12"×13", and Support 8 x 3.5" HDD drive bays, compatible 2.5" HDD/SSD, Standard ATX power supply Or 2U redundant power supply. | |
| 3.The chassis has good ventilation system 3 X 12028 hot plug fans to make sure the system work steadily. | |
